Hempcrete's Permitting Wall: Why It Still Can't Bear Load
Photo by Lucas Pezeta via Pexels.
Walk into a hemp building trade show and you'll hear hempcrete described as a wall material that breathes, stores carbon, and outperforms fiberglass on thermal mass. All of that is defensible. What you won't hear from the podium, unless someone presses the point, is that no building department in the United States currently lets hempcrete hold up a roof by itself. Every permitted hempcrete structure built in this country to date relies on a timber or steel frame doing the actual structural work, with the hemp-lime mix packed around it as insulation.
That changed, partially, in 2024. The International Code Council added Appendix BL to the International Residential Code, giving hemp-lime construction a named, citable path through permitting for the first time. It's a genuine milestone, and it's being treated by some in the industry press as the moment hempcrete arrived. It isn't that. Appendix BL is opt-in, it applies only to low seismic zones, and it explicitly covers non-structural, non-engineered hemp-lime infill -- not a load-bearing wall system.
The reason isn't bureaucratic inertia. It's compressive strength. Conventional hempcrete mixes test out around 1.15 MPa at the high end; engineers generally put the bar for genuine structural use at 3 to 5 MPa, plus a stiffness profile hempcrete doesn't currently have. This piece walks through what's actually codified now, what ASTM's new research call signals about the next few years, and what would realistically have to happen in the lab before a building inspector anywhere signs off on hempcrete as a structural material.
What Hempcrete Actually Is, and What It Isn't Rated For
Hempcrete, in its standard form, is a cast-in-place or sprayed mixture of hemp hurd -- the woody core of the stalk, left over once the bast fiber is stripped off -- combined with a lime-based binder and water. The mix goes into forms or cavities around a frame, cures over weeks, and ends up as a lightweight, highly porous wall infill. None of that description includes the word structural, and that's deliberate: hempcrete was never engineered, chemically or otherwise, to carry a roof load, a seismic shear load, or even its own weight across a wide unsupported span.
What it's genuinely good at is building science most insulation can't touch. The hurd and lime matrix is vapor-open, meaning it lets moisture migrate through the wall assembly rather than trapping it the way a vapor-sealed stud cavity can, which is a real factor in reducing mold and rot risk in certain climates. It also has enough thermal mass to moderate daily temperature swings, and the lime-carbonation process -- where the binder slowly reacts with atmospheric CO2 as it cures -- locks away carbon alongside whatever the hemp plant itself sequestered while growing. These are legitimate, well-documented properties. They're also entirely separate from the question of whether the material can bear weight.
Virtually every hempcrete building constructed in the US so far makes this split explicit in its own construction method. A timber post-and-beam frame, or in some commercial projects a steel frame, carries the dead and live loads -- the roof, the floors, the wind and seismic forces. The hempcrete gets packed into the stud bays or wrapped around the frame as insulation and thermal mass, functioning more like an upgraded version of cavity-fill insulation than like a load-bearing masonry wall. It's a hybrid assembly, not a hempcrete building in the sense that a concrete block building is a concrete building.
That distinction is the spine of everything that follows in this piece. The debate playing out in code bodies and research journals right now isn't about whether hempcrete belongs in a wall assembly -- that's settled, and increasingly permitted. It's about whether hempcrete can ever BE the wall, structurally, without a hidden frame doing the real work. Those are two different engineering questions with two very different timelines, and conflating them is where most of the optimistic industry messaging goes wrong.
The Compressive Strength Problem, in Actual Numbers
Conventional hempcrete's compressive strength (0.2–1.15 MPa) falls far short of the structural threshold (3–5 MPa), but Penn State's modified mix reaches 4.5 MPa, placing it within the structural range.
Numbers settle this debate faster than marketing copy does. Conventional hempcrete mixes, tested across a range of hurd-to-lime ratios, moisture contents and cure times, land somewhere between roughly 0.2 and 1.15 MPa in compressive strength -- about 28 to 167 psi. That's a wide band, and the variability itself is part of the problem: a material that swings by nearly 6x depending on how wet the mix was poured or how long it cured is hard for any code body to write a reliable structural allowance around, even before you ask whether the number is high enough.
And it isn't high enough. One widely cited engineering benchmark puts the threshold for genuine structural, load-bearing use at 3 to 5 MPa -- 435 to 725 psi -- which is three to four times the upper end of what a typical hempcrete mix achieves today. Compressive strength isn't even the whole story. A wall also needs adequate Young's modulus, the measure of how much a material deforms under a given load before it fails. A material can technically hold weight and still be too flexible to serve as a structural wall, racking or deflecting in ways that crack finishes, misalign openings, or in the worst case compromise the load path entirely. Hempcrete's stiffness profile, by most published data, lags even further behind structural requirements than its compressive strength does.
There's real progress on the research side worth naming. Teams at Penn State have tested modified hempcrete formulations -- incorporating additives designed to densify the matrix or improve the lime-hurd bond -- that reach as high as 58 to 655 psi, or roughly 0.4 to 4.5 MPa. That upper figure actually clears the low end of the structural threshold, which is genuinely encouraging. But the range itself tells you the problem isn't solved: a formulation that spans more than a 10x strength variance depending on mix design isn't a standardized, buildable product yet. It's a promising direction in a materials science research program.
That's the core fact this whole article turns on. This is not a paperwork problem waiting on a committee vote. Building codes rate materials based on reproducible, standardized testing -- and testing can't reproduce consistent structural performance from a mix that doesn't yet consistently produce it. Closing that gap is lab work, additive chemistry, and years of coupon testing, not a faster permit application.
IRC Appendix BL: A Real Milestone, With Real Limits
Photo by Thirdman via Pexels.
Appendix BL -- formally Hemp Lime (Hempcrete) Construction -- entered the 2024 edition of the International Residential Code after a multiyear push led by the US Hemp Building Association, which reportedly raised more than $50,000 to fund the technical application and get it through the ICC's code development process. That's a real, hard-won institutional win, and it shouldn't be undersold: getting any new material into a model code body's base text is a slow, document-heavy process, and hemp-lime construction had no such foothold before this.
The IRC matters more than most state-level code tweaks because of how it's used. It's the base residential building code referenced by 49 of the 50 states -- every state except Wisconsin builds its residential permitting rules off some version of the IRC. An appendix landing in the national model code is a necessary precondition for widespread adoption in a way that, say, a single city ordinance never could be.
But read the actual text of Appendix BL carefully and the limits are explicit, not implied. It covers non-engineered hemp-lime construction, and only in jurisdictions classified as low seismic risk. Anywhere seismic risk runs higher than that threshold, the appendix doesn't apply at all -- the project needs a licensed structural engineer to design a custom assembly from scratch, back to case-by-case review. Nowhere in the appendix does hemp-lime get described as load-bearing or structural. It's an infill material permitted within a framed structure, codified for the first time, but still functioning exactly the way hempcrete always has: insulation and thermal mass around someone else's frame.
There's a second limitation that explains most of the real-world friction builders still report: IRC appendices are opt-in by design. The appendix existing in the national code text gives it zero legal force anywhere until a state or local jurisdiction formally adopts it, the same way jurisdictions separately choose whether to adopt IRC appendices covering things like solar-ready provisions or swimming pool barriers. A builder in a state that hasn't adopted Appendix BL is in exactly the same permitting position as before 2024 -- the appendix is sitting in a book that their local building department has no obligation to recognize. That adoption gap is the actual mechanism behind the permitting wall this piece is named for, and it's why the 2024 milestone, while real, didn't instantly change what happens at a permit counter in most of the country.
Who's Actually Adopted It: Minnesota, Austin, and the Patchwork So Far
Photo by Brett Sayles via Pexels.
Adoption is where the appendix stops being a document and starts being enforceable, and so far that's happening one jurisdiction at a time. Minnesota is the clearest case study. The state's Department of Labor and Industry ran a technical advisory process through 2025 and into 2026, ultimately adopting 2024 IRC Appendix BL as the state's minimum standard for hemp-lime construction, with reporting placing the formal adoption around January 2026.
What makes the Minnesota timeline instructive is what builders had to do before that adoption. Without Appendix BL on the books, the only legal route to building a hemp-lime-insulated structure was the Alternative Materials and Methods pathway -- the standard escape valve codes provide for materials that aren't explicitly addressed, but one that requires case-by-case engineering review for every single project. That's slower and more expensive than citing a pre-approved appendix, and it means the cost of building with hempcrete in Minnesota dropped meaningfully the moment the state adopted a document that had already existed, un-enforced locally, since 2024.
Austin, Texas has reportedly moved through its own local adoption process as well, tracked by industry and sustainability-focused communities like the Carbon Leadership Forum. Expect more of these one-off stories over the next few years rather than a single national announcement, because that's structurally how IRC appendix adoption works -- state by state, sometimes city by city, each on its own legislative or regulatory calendar.
There's a useful historical parallel here: straw bale construction. Straw bale also moved into IRC appendix territory and then spent well over a decade working through state-by-state adoption before reaching anything close to broad availability, and even now it isn't universal. If hempcrete's adoption curve rhymes with straw bale's -- and there's no obvious structural reason it wouldn't, since the underlying mechanism is identical code bureaucracy -- builders should expect a long tail of individual state and municipal adoptions stretched across years, not a sudden nationwide switch.
It's also worth repeating what adoption does and doesn't solve. Every one of these approvals, Minnesota's included, is non-structural and infill-only. Adoption removes a real cost and timeline burden from builders working within the rules that already exist. It does nothing to raise hempcrete's compressive strength or move the material one inch closer to a load-bearing rating. Those are two separate problems, solved by two entirely different institutions working on two entirely different timelines.
The ASTM Research Call: What It Signals and What It Doesn't
Photo by Ivan S via Pexels.
In mid-October 2026, ASTM International issued a call for research papers for a special issue of its Journal of Testing and Evaluation, focused squarely on hemp-lime's engineering properties and the possible routes toward formal standardization. For an industry that's spent years watching code bodies move cautiously, this is worth paying attention to -- it's the first time a major standards organization has organized a dedicated research push around hemp-lime specifically.
The scope of what ASTM is soliciting is broad by design: thermal performance, moisture behavior, mechanical and compressive properties, long-term durability, fire safety, standardized testing methodology, prefabricated hemp-lime products, installation methods, even 3D-printing applications and in-situ building performance data. That breadth is itself a signal -- it tells you the field doesn't yet have agreed-upon test methods for most of these properties, which is precisely the gap that's kept hempcrete out of structural code language in the first place.
It's important to be precise about what this call actually is, because it's easy to overstate. This is a solicitation for research submissions to a journal special issue -- not a new ASTM standard, not a draft standard in balloting, not even a committee proposal yet. Readers should not read this as ASTM signaling an imminent structural rating is on the way. It's the research-gathering stage that, if successful, might eventually feed into a standards committee's work years down the line.
Hempcrete already intersects with ASTM in narrower ways that are worth naming so they're not confused with this new effort. ASTM E84 covers surface burning characteristics and flame spread, and ASTM E119 covers fire-resistance ratings for building materials and assemblies -- both are existing, usable standards relevant to hempcrete's fire performance, and both speak to fire behavior, not compressive load capacity. A hempcrete assembly can have a perfectly good E119 fire rating and still have no structural rating whatsoever; they're unrelated code questions.
History gives a reasonable yardstick for how long this kind of research-to-standard pipeline takes. Standardized test methods for other alternative materials -- straw bale again, and cross-laminated timber in its earlier commercialization years -- typically took five-plus years to move from a formal research push to a usable ASTM standard that a builder could actually cite in a permit application. There's no reason to assume hemp-lime moves meaningfully faster, since the underlying obstacle -- reproducible test methods for a naturally variable bio-composite material -- is the same category of problem CLT and straw bale both had to solve first.
What Would Actually Have to Happen for Load-Bearing Hempcrete
Photo by Saeed Khokhar via Pexels.
There's a reasonable, evidence-based case for optimism here, so it's worth stating plainly. If Penn State-style additive research keeps closing the gap and reliably pushes mixes past the 3 MPa threshold with acceptable stiffness -- not just in a single lab trial but across reproducible formulations -- and if ASTM's research issue yields an actual standardized test method within the next few years, a genuine structural ASTM standard for hemp-lime becomes plausible sometime this decade. That's a forecast grounded in the straw bale and CLT timelines discussed above, not wishful extrapolation: both of those materials eventually got there, on roughly five-to-ten-year research-to-standard arcs.
The counter-case deserves equal weight, because it's just as grounded in the chemistry. Hemp hurd is a low-density, highly porous aggregate by nature -- that porosity is exactly what gives hempcrete its vapor permeability and thermal mass in the first place. Additives that densify the matrix and push compressive strength upward tend to work by reducing that porosity, which risks trading away the very properties that make hempcrete worth building with over a conventional insulated stud wall. There's a real possibility that a mix strong enough to be structural is, by the time you've added enough binder and densifier to get there, no longer the breathable, carbon-storing material anyone wanted in the first place. It becomes a different, less interesting composite wearing hempcrete's name.
A more conservative and plausibly nearer-term path already has precedent in parts of Europe: hybrid assemblies where hempcrete functions as a permanent insulating form wrapped around a thin structural core of timber or concrete, rather than chasing a pure hempcrete structural rating at all. This sidesteps the compressive strength problem entirely by never asking hempcrete to do structural work, while still capturing most of its insulation and carbon benefits.
For builders and investors scanning this space for near-term opportunity, the more durable play right now probably isn't a bet on a stronger hempcrete arriving on schedule. It's the permitting and engineering-services niche: firms that specialize in Alternative Materials and Methods submissions, and structural engineers who can design code-compliant hemp-lime assemblies for higher seismic zones Appendix BL doesn't cover. That work is needed today, regardless of what happens in a materials lab over the next five years.
On the policy side, the more procedurally realistic expectation is a steady drumbeat of state DLI-style technical advisory adoptions of Appendix BL over the next one to three years, following Minnesota's template, well ahead of any structural standard. Adopting an existing non-structural appendix is an administrative decision measured in months; writing new structural code language from scratch is a multiyear undertaking requiring data this field doesn't yet have.
Put the 2024 IRC Appendix BL and the October 2026 ASTM research call next to each other and what you see is a sequence, not a surprise. Each is a real, documented step -- an opt-in code appendix on one hand, a formal research solicitation on the other -- and each sits on a code-adoption and standards-development clock that has historically run well over a decade from first appendix to structural standard, based on how straw bale and cross-laminated timber actually got there. Nothing in the current record suggests hempcrete is about to break that pattern.
Anyone evaluating hempcrete as a business or investment proposition should treat structural hempcrete as exactly what it is: a multiyear materials-science bet, not a regulatory formality waiting to be cleared. The leading indicators worth actually watching are narrow and technical -- whether Penn State-style additive formulations keep producing reproducible strength gains above 3 MPa without gutting vapor permeability, and whether ASTM's special issue actually produces a standardized test method rather than just a collection of interesting papers. State adoption announcements make for better headlines, but they're lagging indicators of permitting convenience, not of the underlying strength problem.
The more useful near-term read may be that the interesting opportunity isn't a stronger hempcrete at all. It's the services layer built around the non-structural material that already works today -- engineers who know how to get a hemp-lime project through Alternative Materials and Methods review, and consultants who can navigate the growing but uneven patchwork of Appendix BL adoptions. That business doesn't need the compressive strength problem solved. It needs the rules that already exist to be navigated faster, and that's a market opening now, years ahead of whatever the lab eventually produces.
